Product Details
-
Resolution
25nm
-
Positioning Accuracy
±50nm
-
Angle Axis
±0.003°
- Utilises high-precision pressure sensors,achieving micron-level precision control of the spacingbetween the PIC and the FA.
- Primarily employs linear motor drives witha closed-loop precision of 25 nm, to meet the high-precision coupling requirements of photonic integrated circuit products.
- Employs force-feedback high-precision electric suction-clamping integrated grippers to achieve high-precision,stable gripping of the FA.
- High-precision spectral confocal laser sensors areemployed to achieve high-precision attitude calibrationof the FA and the chip.
Application Fields
-
optical fiber communication
-
fiber optic sensing
-
High power laser
-
Laser projection
